Main Chassis
47
10
Converter Board
WARNING:
Before working inside your computer, read the safety information that
shipped with your computer. For additional safety best practices information, see
the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
Removing the Converter Board
1 Follow the instructions in "Before You Begin" on page 11.
2 Remove the back cover. See "Removing the Back Cover" on page 19.
3 Remove the rear-stand assembly. See "Removing the Rear-Stand Assembly"
4 Remove the VESA mount. See "Removing the VESA Mount" on page 37.
5 Remove the rear I/O cover. See "Removing the Rear I/O Cover" on page 39.
6 Disconnect the converter-board cable from the connector on the converter
board.
7 Remove the two screws that secure the converter board to the chassis.
8 Lift the converter board away from the chassis.
