Display 109
26
Display
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
Display Assembly
Removing the Display Assembly
1 Follow the instructions in "Before You Begin" on page 11.
2 Remove the back cover. See "Removing the Back Cover" on page 19.
3 Remove the rear-stand assembly. See "Removing the Rear-Stand Assembly"
on page 35.
4 Remove the feet. See "Removing the Feet" on page 69.
5 Follow the instructions from step 3 to step 5 in "Removing the Optical
Drive" on page 27.
6 Remove the VESA mount. See "Removing the VESA Mount" on page 37.
7 Remove the rear I/O cover. See "Removing the Rear I/O Cover" on page 39.
8 Remove the side I/O cover. See "Removing the Side I/O Cover" on page 41.
9 Remove the system-board shield. See "Removing the System-Board
Shield" on page 53.
10 Remove the AV board. See "Removing the Audio Video (AV) Board" on
page 43.
11 Remove the processor heat-sink fan. See "Removing the Processor
Heat-Sink Fan" on page 75.
