I/O Cover
39
8
I/O Cover
WARNING:
Before working inside your computer, read the safety information that
shipped with your computer. For additional safety best practices information, see
the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
Rear I/O Cover
Removing the Rear I/O Cover
1 Follow the instructions in "Before You Begin" on page 11.
2 Remove the back cover. See "Removing the Back Cover" on page 19.
3 Remove the rear-stand assembly. See "Removing the Rear-Stand Assembly"
4 Remove the four screws that secure the rear I/O cover to the chassis.
5 Lift the rear I/O cover away from the chassis.
