Dell Inspiron 1420 (Mid 2007) User Manual
Page 18
3.
Replace the six M2 x 3-mm screws (three on each side) to secure the display bracket to the display panel.
4.
Connect the camera module cable from the connector.
5.
Connect the top flex-cable connector to the display locking connector on the new display panel.
6.
Connect the bottom flex-cable connector to the inverter connector.
7.
Gently place the display panel inside the display cover.
8.
Replace the two screws securing the display panel to the display (top) cover.
9.
Replace the display bezel (see
).
10.
Replacing the Display Assembly
11.
Replace the left and right hinge covers by pressing them in place.
12.
Replace the keyboard (see
Replacing the Keyboard
).
13.
Replace the keyboard cover (see
Replacing the Keyboard Cover
).
Back to Contents Page
NOTICE:
To avoid damaging the display cover and/or the display panel, ensure that the guide posts at the top of the display panel are properly aligned
with the corresponding notches on the display cover.
