7
The Dell Wireless Dock D5000 has the below I/O connectors:
Video Ports  DisplayPort x 1
 HDMI x 1
Input/Output
Ports  USB 3.0 x 3
 Gigabit Ethernet
 Audio Jack x 1 (Microphone-in and line-out via combo
connector)
If the wireless link between the computer and the Dell Wireless Dock
becomes weak, move the computer closer to the Dell Wireless Dock or rotate
the computer to find a position with a stronger wireless link. For example, if you
find that the wireless signal strength is reduced when the notebook lid is closed,
you can try to rotate the notebook to find the best reception.
Note: The wireless connection works best if your computer lid (logo side)
directly faces the front side of the docking station and there is a line-of-sight
between the computer and the docking station.
3.2.1 Using The Network Port
When you want to use Internet via the network port of the docking station, you
just plug the network cable into the network port of the docking station. The
meanings of the LED indicators on the network port are listed below:
Link Speed Indicator Ethernet Activity Indicator
Green = 10/100 Mb
Yellow Flashing
Orange = 1 Gb
Figure 5. Ethernet
