10
Setting up Your Computer
1 front panel
LEDs (3) Multi-colored LEDs provide illumination for the
front of the computer.
2 front I/O
connectors Plug USB and other devices into the appropriate
connectors (see "Front I/O Connectors" on page 12).
3 3.5-inch drive
bays (2) Can hold optional devices such as a Media Card
Reader.
NOTE:
The Service Tag and Express Service Code are
located on a label inside this bay door.
4 5.25-inch drive
bays (4) Can hold an optical or SATA hard drive in a
5.25-inch drive bay carrier.
NOTE:
The hard drive carrier is only for use in the
5.25-inch drive bays. The floppy-drive/Media Card
Reader and hard drive carriers are not
interchangeable.
5 front panel
LEDs (4) Multi-colored LEDs provide illumination for the
front of the computer.
6 optical drive
tray eject
buttons (4) Use to eject the drive tray of an optical drive.
NOTE:
The optical drive tray eject button is not a
handle. The self-tending doors open automatically
when the eject button is pressed and the drive tray is
ejected.
7 front panel
LEDs (3) Multi-colored LEDs provide illumination for the
front of the computer.
8 power button Press to turn on the computer.
CAUTION:
To avoid losing data, do not use the
power button to turn off the computer. Instead,
perform an operating system shutdown.
NOTE:
The power button can also be used to wake the
system or to place it into a power-saving state.
