Camera
Dell™ Inspiron™ One 19 Service Manual
Removing the Camera
1.
Follow the procedures in
Before You Begin
.
2.
Remove the display bezel (see
Removing the Display Bezel
).
3.
Disconnect the camera cable from the connector on the camera module.
4.
Using a plastic scribe, pry out the camera module to release it from the chassis.
5.
Lift the camera module off the chassis.
Replacing the Camera
1.
Follow the procedures in
Before You Begin
.
2.
Using the glue that shipped with the new camera module, affix the camera module on the chassis.
3.
Connect the camera cable to the connector on the camera module.
4.
Replace the display bezel (see
Replacing the Display Bezel
).
5.
Connect your computer and all attached devices to electrical outlets, and turn them on.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
1
camera
2
camera-cable connector
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
