6-50
Linksys SPA9000 Administrator Guide
Document Version 3.01
Chapter 6 SPA9000 Field Reference
Line 1/2/3/4 Tab
Subscriber Information
Refer-To Target Contact To contact the refer-to target, select yes. Otherwise, select no.
The default is no.
Field Description
Display Name Display name for caller ID.
User ID Extension number for this line.
Password Password for this line.
Use Auth ID To use the authentication ID and password for SIP authentication, select yes. Otherwise,
select no to use the user ID and password.
The default is no.
Auth ID Authentication ID for SIP authentication.
Call Capacity Maximum number of calls allowed on this line interface. Choices: {unlimited,1,2,3,…25
}. Default is 16. Note that the SPA9000 does not distinguish between incoming and
outgoing calls when talking about call capacity. Note: unlimited = 16
