6-3
Linksys SPA9000 Administrator Guide
Document Version 3.01
Chapter 6 SPA9000 Field Reference
Info Tab
Line 1/2/3/4 Status
)
FXS 1/2 Status
Field Description
Registration State
Last Registration At Last date and time the line was registered.
Next Registration In Number of seconds before the next registration renewal.
Message Waiting Indicates whether you have new voicemail waiting: Yes or No. This is updated when
voicemail notification is received. You can also manually modify it to clear or set the flag.
Setting this value to Yes can activate stutter tone and VMWI signal. This parameter is
stored in long term memory and survives after reboot or power cycle.
Mapped SIP Port Port number of the SIP port mapped by NAT.
Field Description
Hook State Status of phone readiness. On indicates that the phone is ready for use; Off indicates that
the phone is in use.
Message Waiting Indicates whether you have new voicemail waiting: Yes or No. This is updated when
voicemail notification is received. You can also manually modify it to clear or set the flag.
Setting this value to Yes can activate stutter tone and VMWI signal. This parameter is
stored in long term memory and survives after reboot or power cycle.
Call Back Active Indicates whether a call back request is in progress: Yes or No.
Last Called Number Last number called.
Last Caller Number Number of the last caller.
Mapped SIP Port Port number of the SIP port mapped by NAT.
Call 1/2 State Status of the call.
Call 1/2 Tone Type of tone used by the call.
Call 1/2 Encoder Codec used for encoding.
Call 1/2 Decoder Codec used for decoding.
Call 1/2 FAX Status of the fax pass-through mode.
Call 1/2 Type Direction of the call.
Call 1/2 Remote Hold Indicates whether the far end has placed the call on hold.
Call 1/2 Callback Indicates whether the call was triggered by a call back request.
Call 1/2 Peer Name Name of the internal phone.
