22
Dell™ PowerEdge™ 4210 Installation Guide
Figure 1-9. Attaching the Front Stabilizer Foot
To install a side stabilizer foot, perform the following steps:
1 Remove the side panel.
2 On the side of the rack frame’s bottom rail, locate the three threaded holes
(see Figure 1-10).
3 Position the stabilizer foot against the base of the rack frame and align its
holes with the corresponding holes in the frame.
1 front stabilizer foot
1
