Dell™ PowerEdge™ 4210 Installation Guide
13
Replacing the Back Doors
To replace the back doors, perform the steps for removal in reverse.
Removing the Side Panels
CAUTION:
Because of the size and weight of the rack cabinet side panels, never
attempt to remove or install them by yourself.
NOTE:
You must remove the side panels in order to install the side stabilizer feet.
Also, although removing the side panels is not mandatory for installing systems in a
rack, having the sides open makes it easier to install slide assemblies and support
rails and to reverse the direction that the front door opens.
1 Unlock the locks near the left and right edges of the panel (see Figure 1-4).
Figure 1-4. Removing a Side Panel
1 side panel (2) 2 locks (2)
3 handles (2)
1
2
3
