Dell™ PowerEdge™ 4210 Installation Guide
Removing the Door Panels From the Optional Door Kit
If you purchase the optional door kit, do the following to remove the door
panels:
1 Install the doors according to instructions provided in the door kit.
2 Open the rack doors and locate the panel at the top of each door.
3 One panel at a time, loosen captive screws on the bottom of the panel.
4 Grab the sides of the panel and pull up to unseat them from the door.
5 Repeat steps 3 and 4 on the other door panel.
Coupling Two Racks
CAUTION:
Because of the size and weight of the rack cabinets, never attempt to
couple two rack cabinets by yourself.
1 Unpack and set up both racks.
2 Unpack the coupling kit, shown in Figure 1-13.
The contents of the rack coupling kit include:
• Four gasket strips
• Four hexagonal spacers
• Eight Allen screws
• A stamped-metal crescent wrench
• A T-handle Allen wrench
