CY8C20x36/46/66, CY8C20396

Document Number: 001-12696 Rev. *D

Page 17 of 34

Absolute Maximum Ratings

Exceeding maximum ratings may shorten the useful life of the device. User guidelines are not tested.

Operating Temperature

DC Chip-Level Specifications

The following table lists guaranteed maximum and minimum specifications for the entire voltage and temperature ranges.

Table 12. Absolute Maximum Ratings

Symbol

Description

Conditions

Min

Typ

Max

Units

T

STG

Storage Temperature

Higher storage temperatures reduces data
retention time. Recommended Storage
Temperature is +25°C ± 25°C. Extended
duration storage temperatures above 85

o

C

degrades reliability.

–55

+25

+125

°C

Vdd

Supply Voltage Relative to Vss

–0.5

+6.0

V

V

IO

DC Input Voltage

Vss – 0.5

Vdd + 0.5

V

V

IOZ

DC Voltage Applied to Tri-state

Vss –0.5

Vdd + 0.5

V

I

MIO

Maximum Current into any Port Pin

–25

+50

mA

ESD

Electro Static Discharge Voltage

Human Body Model ESD

2000

V

LU

Latch up Current

In accordance with JESD78 standard

200

mA

Table 13. Operating Temperature

Symbol

Description

Conditions

Min

Typ

Max

Units

T

A

Ambient Temperature

–40

+85

°C

T

J

Operational Die Temperature

The temperature rise from ambient to junction
is package specific. Refer the table

Thermal

Impedances per Package on page 28

. The

user must limit the power consumption to
comply with this requirement.

–40

+100

°C

Table 14. DC Chip-Level Specifications

Symbol

Description

Conditions

Min

Typ

Max

Units

Vdd

Supply Voltage

Refer the table

DC POR and LVD

Specifications on page 21

1.71

5.5

V

I

DD24

Supply Current, IMO = 24 MHz

Conditions are Vdd = 3.0V, T

A

= 25°C,

CPU = 24 MHz. CapSense running at 12
MHz, no IO sourcing current

2.88

4.0

mA

I

DD12

Supply Current, IMO = 12 MHz

Conditions are Vdd = 3.0V, T

A

= 25°C,

CPU = 12 MHz. CapSense running at 12
MHz, no IO sourcing current

1.71

2.6

mA

I

DD6

Supply Current, IMO = 6 MHz

Conditions are Vdd = 3.0V, T

A

= 25°C,

CPU = 6 MHz. CapSense running at 6 MHz,
no IO sourcing current

1.16

1.8

mA

I

SB0

Deep Sleep Current

Vdd = 3.0V, T

A

= 25°C, IO regulator turned off

0.1

μA

I

SB1

Standby Current with POR, LVD and
Sleep Timer

Vdd = 3.0V, T

A

= 25°C, IO regulator turned off

1.07

1.5

μA
