4.2.3. Read / write parameter target (profile), command „S“ (53h)
This command is for readout the presently active target or for programming respectively reading a specific
target. The data are composed of profile number (2 bytes) and target (6 bytes). Important: Negative targets
come with 5 digits only (see example no. 3).
Example 1: Read active target (current profile number = 12; target = 12,50)
SOH Adr Cmd EOT CRC
Transmission
01h 20h 53h 04h 2A
SOH Adr Cmd Profile no. = 12 Target = 12,50 EOT CRC
Response
01h 20h 53h 31h 32 30h 30h 31h 32h 35h 30h 04h 3E
Response upon deletion of all targets:
SOH Adr Cmd Profile no. =
FFh
Target = FFFFFFh EOT CRC
Response
01h 20h 53h 3Fh 3F 3Fh 3Fh 3Fh 3Fh 3Fh 3Fh 04h 2Ah
Example 2: Read target of a specific profile (profile number = 17; target = 12,50)
SOH Adr Cmd Profile no. = 17 EOT CRC
Transmission
01h 20h 53h 31h 37h 04h 16h
SOH Adr Cmd Profile no. = 17 Target = 12,50 EOT CRC
Response
01h 20h 53h 31h 37h 30h 30h 31h 32h 35h 30h 04h BCh
Example 3: Write target of a specific profile (profile number = 17; target = -12,50)
s
SOH Adr Cmd Profile no. = 17 Target = -12,50 EOT CRC
Transmission
01h 20h 53h 31h 37h 2Dh 30h 31h 32h 35h 30h 04h FBh
SOH Adr Cmd Profile no. = 17 Target = -12,50 EOT CRC
Response
01h 20h 53h 31h 37h 2Dh 30h 31h 32h 35h 30h 04h FBh
Direct positioning „SD“
This command may be utilized for direct positioning operations with direct programming of a position value.
Only the target less any profile number is transmitted to SPA. The profile number after the command “S” is
replaced by sub command “D” (0 = dimension). Any previously programmed profiles are not overwritten.
Example 4: Write position value for direct positioning (less profile)
SOH Adr Cmd Sub Position value = 278,25 EOT CRC
Transmission
01h 20h 53h 44h 30h 32h 37h 38h 32h 35h 04h 6Bh
SOH Adr Cmd Sub Position value = 278,25 EOT CRC
Response
01h 20h 53h 44h 30h 32h 37h 38h 32h 35h 04h 6Bh
Note: The position value is saved in the non-volatile memory and will be retained in case of power failure. In this
case the previously selected profile will be applied again.
If an IVO master is utilized, the target is reset to the previously defined profile value after having quit dimension
mode (DIM mode).
4.2.4. Read / write parameter profile number, command „V“ (56h)
This command is for readout the number of the presently active profile respectively for profile alteration.
Example 1: Read active profile (active profile number = 38)
SOH Adr Cmd EOT CRC
Transmission
01h 20h 56h 04h 20h
SOH Adr Cmd Profile no. = 38 EOT CRC
Response
01h 20h 56h 33h 38h 04h 28h
