N 140
www.baumer.com 10
Example 2: Align actual value with preset (preset = 17,25)
SOH Adr Cmd Preset = 17,25 EOT CRC
Transmission
01h 20h 5Ah 30h 30h 31h 37h 32h 35h 04h 09h
SOH Adr Cmd Preset = 17,25 EOT CRC
Response
01h 20h 5Ah 30h 30h 31h 37h 32h 35h 04h 09h
Example 3: Align actual value with preset at all SPAs by broadcast command
SOH Adr Cmd Preset = 17,25 EOT CRC
Transmission
01h 83h 5Ah 30h 30h 31h 37h 32h 35h 04h AAh
Response Not confirmed
4.2.7. Readout any optional number sequence in the upper line of display,
command „t“ (74h)
This command is to indicate a 6-digit number sequence in the upper line of the display. The sequence is
indicated without dot respectively comma. Preceding zeroes as well as both direction arrows are suppressed.
The bottom line still indicates the current value.
The number is shown on the display until any command except „t“, „u“ or „R“ is received by interface. The
number will be retained after power failure.
Example: (number sequence = 654321)
SOH Adr Cmd Number sequence = 654321 EOT CRC
Transmission
01h 20h 74h 36h 35h 34h 33h 32h 31h 04h 47h
SOH Adr Cmd Number sequence = 654321 EOT CRC
Response
01h 20h 74h 36h 35h 34h 33h 32h 31h 04h 47h
4.2.8. Readout any optional number sequence in the bottom line of display,
command „u“ (75h)
The command is for indicating a 6-digit number in the bottom line of the display. The number is indicated
without dot respectively comma. Preceding zeroes as well as both direction arrows are suppressed. The upper
line still indicates the current target or tool number.
The number sequence is displayed until any optional command except „t“, „u“ or „R“ is received by the interface.
The number will be retained after power failure.
Example: (number sequence = 123456)
SOH Adr Cmd Number sequence = 123456 EOT CRC
Transmission
01h 20h 75h 31h 32h 33h 34h 35h 36h 04h BCh
SOH Adr Cmd Tool number = 123456 EOT CRC
Response
01h 20h 75h 31h 32h 33h 34h 35h 36h 04h BCh
Important:
Command “t” in conjunction with command “u” enables displaying a 12-digit number.
Tool number and number sequence are not saved.
