N 143
26 www.baumer.com
4.5.3. Read version or serial number „X“ (58h)
This command reads out version number, device type or serial number. The following sub-commands are avail-
able:
Data = V (56h) = read out version number
Data = T (54h) = read out device type
Data = S (53h) = read out serial number
Example 1: Read out version number
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h 56h 04h D8h
SOH Adr Cmd Data Versionsnummer = 2.00 EOT CRC
Response
01h 20h 58h 56h 20h 32h 30h 30h 04h FAh
Example 2: Read out device type (Device type = 82h = N 143; software no. = 01)
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h 54h 04h DCh
SOH Adr Cmd Data Typ EOT CRC
Response
01h 20h 58h 54h 82h 81h 04h 6Eh
Structure of the encoded device type transmitted:
1 0 0 1 0 1 0 1 1 0 0 0 0 0 0 1 = 95 81 hex
┬ ──────┬────── ┬ ───────┬─────
│ │ │ └─────── software no. 01h = software 01
│ │ └──────────────── ever 1
│ └────────────────────────── device type 15h = N 155
└────────────────────────────────── ever 1
Example 3: Read out serial number
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h 53h 04h D2h
SOH Adr Cmd Data Encoded serial number = 07090EA4 EOT CRC
Response
01h 20h 58h 53h 30h 37h 30h 39h 30h 3Eh 3Ah 34h 04h 20h
Structure of the encoded serial number transmitted:
The Low-Nibble (lower 4 bits of a byte) of the 8 data bytes received equal a 4-byte value encoding the serial
number.
The serial number is composed of production date and time. Since the seconds come encoded as well and per
second only one number will be allocated, the serial number is unique and unambiguous.
Example: serial number for production date and time 01.06.2005 16:58:36 = 15 83 0E A4 hex
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X Bit position
J J J J J J M M M M T T T T T h h h h h m m m m m m s s s s s s content
0 0 0 1 0 1 0 1 1 0 0 0 0 0 1 1 0 0 0 0 1 1 1 0 1 0 1 0 0 1 0 0 example = 15 83 0E A4 hex
─────┬───── ────┬──── ────┬──── ─────┬───── ──────┬────── ─────┬─────
│ │ │ │ │ └─────── seconds 10 0100 = 24h = 36d
│ │ │ │ └──────────────────── minutes 11 1010 = 3Ah = 58d
│ │ │ └───────────────────────────────── hours 1 0000 = 10h = 16d
│ │ └──────────────────────────────────────────── day 0 0001 = 01h = 01d
│ └────────────────────────────────────────────────────── month 0110 = 06h = 06d
└───────────────────────────────────────────────────────────────── year 00 0101 = 05h = 05d
│
01.06.05 16:58:36 <──────┘
