CY7C1329H
Document #: 38-05673 Rev. *B Page 5 of 16
Interleaved Burst Address Table
(MODE = Floating or V
DD
)
First
Address
A
1
, A
0
Second
Address
A
1
, A
0
Third
Address
A
1
, A
0
Fourth
Address
A
1
, A
0
00 01 10 11
01 00 11 10
10 11 00 01
11 10 01 00
Linear Burst Address Table (MODE = GND)
First
Address
A
1
, A
0
Second
Address
A
1
, A
0
Third
Address
A
1
, A
0
Fourth
Address
A
1
, A
0
00 01 10 11
01 10 11 00
10 11 00 01
11 00 01 10
ZZ Mode Electrical Characteristics
Parameter Description Test Conditions Min. Max. Unit
I
DDZZ
Sleep mode standby current ZZ > V
DD
– 0.2V
40 mA
t
ZZS
Device operation to ZZ ZZ > V
DD
– 0.2V 2t
CYC
ns
t
ZZREC
ZZ recovery time ZZ < 0.2V 2t
CYC
ns
t
ZZI
ZZ Active to sleep current This parameter is sampled 2t
CYC
ns
t
RZZI
ZZ Inactive to exit sleep current This parameter is sampled 0 ns
