CBM-270 User’s Manual
CITIZEN 33
5555....3333 JJJJuuuum m m mppppeeeer r r r W W W Wiiiirrrre e e e F FF Fuuuunnnnccccttttiiiioooonnnn
The jumper wires have been set at shipment. The following lists the basic settings at
shipment. Check the settings by performing self-printing.
Jumper Wires
No. Function Short Open
Upon
Shipment
J1 Short
J2 See Table 3 Short
J3
International character
Short
J4 Data bit length 7 bits 8 bits Open
J5 Unused - - Open
J6 Label detection Black mark Label interval Open
J7 Unused - - Open
J8 Communication error mark Ignored "?" printed Open
* J4: Serial interface only. Disabled for the parallel one.
* J5
~ J7: Do not change the shipment settings.
Table 3
No. USA France Germany U.K. Denmark-I Sweden Italy Japan
J1 Short Open Short Open Short Open Short Open
J2 Short Short Open Open Short Short Open Open
J3 Short Short Short Short Open Open Open Open
C C C CA A A AU U U UT TT TIIIIO O O ON N N N::::
1) Never change the settings of the jumper wires.
2) If you want to change their settings, consult us.
3) Never disassemble the printer body. It could cause trouble, etc.
