Options
6 DA-10352-00A-001
Compaq AlphaServer GS60E
Storage Devices
When multiple storage devices are configured with
the system, specify which devices should be
installed inside the system cabinet, inside the
system expansion cabinet, or installed in the
external StorageWorks cabinet. Line item
sequencing allows Manufacturing to configure
storage options in the appropriate cabinet.
List storage options to be integrated in system
cabinet immediately following system part
number.
List storage options to be integrated in
StorageWorks cabinet immediately following
StorageWorks cabinet part number.
Internal Storage
System cabinet provides space for up to four
BA36R-RC/RD StorageWorks shelves; each
shelf holds a maximum of two 5.25 ″ devices and
one 3.5 ″ device or seven 3.5 ″ devices.
System cabinet includes one UltraSCSI
StorageWorks shelf (BA36R-RC) and one PCI
shelf (DWLPB-DA).
UltraSCSI Options
Each UltraSCSI StorageWorks shelf requires SCSI
controller and SCSI cable to connect controller to
shelf; refer to UltraSCSI Configuration Guidelines
(EK-ULTRA-CG.C01).
UltraSCSI single-channel
StorageWorks shelf (included) with
16-bit I/O personality module (DS-
BA35X-FA), 180W AC power
supply, DC fans, RETMA
rackmounting hardware; supports
16-bit UltraSCSI devices and some
8-bit narrow SCSI devices
depending on compliance with
minimum revision levels
BA36R-RC
UltraSCSI dual-channel StorageWorks
shelf, includes 16-bit I/O personality
module (DS-BA35X-FB), 180 W AC
power supply, DC fans, RETMA
rack-mounting hardware; supports
16-bit UltraSCSI devices and some
8-bit narrow SCSI devices,
depending on compliance with
minimum revision levels.
BA36R-RD
Power Option for BA36R Shelves
An additional power supply provides N+1 power for
StorageWorks shelves; power supply uses 3.5 ″
slot in StorageWorks shelf, reducing total number
of devices supported by one.
180W 120 VAC Redundant Power
Supply for StorageWorks shelf
CK-BA35X-HH
SCSI Signal Converter
UltraSCSI StorageWorks DOC
Signal Converter, required to
convert FWD signals from
KZPBA-CB to single-ended for
connection to DS-BA35X-FA
personality module in Storage-
Works shelf, field installed only
DS-BA35X-DA
Internal Storage (continued)
SCSI Signal Converter (continued)
Fast20 Personality Module for BA356
single-ended-to-single-ended
1-channel, field installed only
DS-BA35X-FA
Fast20 Personality Module for BA356
single-ended-to-single-ended
2-channel, field installed only
DS-BA35X-FB
Cable for above BN38C-02
UltraSCSI Hubs
UltraSCSI hubs are supported with KZPBA-CB PCI
differential SCSI adapters.
UltraSCSI Hub with three differential
ports (two host ports and one
storage port), no single-ended
ports, in 3.5 ″ SBB, UltraSCSI
cables not included
DS-DWZZH-03
UltraSCSI Hub with five differential
ports, no single ended ports,
consists of four host ports and
one storage port in 5.25 ″ SBB,
UltraSCSI cables not included
DS-DWZZH-05
UltraSCSI Hub with one differential
port and two single-ended ports
in 3.5 ″ SBB, UltraSCSI cables
not included
DS-DWZZH-21
16-bit Wide Drives
36.4-GB 10,000 rpm 16-bit
UltraSCSI disk drive SBB (not
supported on KZPAC controllers)
DS-RZ1FB-VW
18.2-GB 10,000 rpm 16-bit
UltraSCSI disk drive SBB (not
supported on KZPAC controllers)
DS-RZ1ED-VW
18.2-GB 7200 rpm 16-bit UltraSCSI
disk drive SBB (not supported on
KZPAC controllers)
DS-RZ1EA-VW
9.1-GB 10,000 rpm 16-bit UltraSCSI
disk drive SBB
DS-RZ1DD-VW
9.1-GB 7200 rpm 16-bit UltraSCSI
disk drive SBB
DS-RZ1DA-VW
Tape Devices
Tape drives not supported with KZPAC RAID
controller
8-GB DAT 3.5 ″ SCSI tape drive in
StorageWorks carrier; requires
OpenVMS V6.2-1H3 or later or
Tru64 UNIX V3.2C or later and
System Console Firmware
Revision 3.0-9
TLZ09-VA
32/64-GB DAT tape loader in
StorageWorks carrier
TLZ9L-VA
12/24-GB 4mm DAT SCSI tape drive
in StorageWorks carrier
DS-TLZ10-VA
20/40-GB DLT SCSI tape drive in
5.25 ″ StorageWorks carrier
TZ88N-VA
35/70-GB DLT SCSI tape drive in
5.25 ″ StorageWorks carrier
DS-TZ89N-VW
Solid State Disks
Supported with KZPBA controller
