Compaq AlphaServer GS60E

Storage Controllers (continued)

PCI UltraSCSI Controllers (continued)
PCI 3-port RAID (FWSE) controller

(UltraSCSI-ready) with 4-MB cache

memory (uses 2 PCI slots) allows

RAID levels 0, 0+1, 1, and 5;

includes RAID Array 230/plus

subsystem software and

documentation kit;

3X-KFE72-LA option required to run

RCU; tape and optical drives not

supported; four per PCI, maximum

of four per system; requires BN31K-

0E or KZPAC-SB for third port

connection

KZPAC-CA

PCI 3-port RAID (FWSE) controller

(UltraSCSI-ready) with 8-MB cache

memory (uses two slots) allows

RAID levels 0, 0+1, 1, and 5;

includes RAID Array 230/plus

subsystem software and

documentation kit;

3X-KFE72-LA option required to run

RCU; tape and optical drives not

supported; four per PCI, maximum

four per system; requires BN31K-0E

or KZPAC-SB for third port

connection

KZPAC-CB

SCSI cable/bulkhead assembly kit with

two ports for KZPAC-CA/CB; allows

connection of one third port outputs

using one PCI bulkhead slot

KZPAC-SB

SCSI cable/bulkhead assembly kit with

one port for KZPAC-CA/CB, allows

connection of one third port output

using one PCI bulkhead slot

BN31K-0E

1-m VHDCI male-to-VHDCI male

UltraSCSI cable, connects KZPAC

to front-mounted StorageWorks

shelf.

BN37A-01

2-m VHDCI male-to-VHDCI male

UltraSCSI cable, connects KZPAC

to rear-mounted StorageWorks

shelf.

BN37A-02

Battery backup for cache memory

option for KZPAC controller,

recommended for all KZPAC

controllers

KZPSC-UB

8-MB cache memory option

MS100-BB

DSSI and CI Adapters (OpenVMS only)
PCI DSSI adapter, 12 per PCI, maximum

of 24 per system (KFPSA, KFMSB

not supported on same DSSI bus)

KFPSA-AA

External shielded cable (MR/MR

connectors); select length—09, 16,

25 feet

BC29S-xx

External shielded cable (MR/PS

connectors); select length—06, 09,

16, 30 feet

BC29R-xx

PCI CI adapter, four per PCI, maximum

of 26 per system; requires two PCI

slots for adapter and power

CIPCA-AA

Storage Controllers (continued)

DSSI and CI Adapters (OpenVMS only)

(continued)

Same as CIPCA-AA except uses two

PCI slots for adapter

CIPCA-BA

Computer interconnect cable sets;

connects CIPCA to Star Coupler;

select length—10, 20, 45 m

BNCIA-xx

External Storage Controllers

HSZ70 UltraSCSI RAID Array controllers are

supported under Tru64 UNIX V3.2G, V4.0B or

later and OpenVMS V6.2-1H3 for direct

attachments or OpenVMS V7.1-1H1 or later for

cluster support.

HSJ50 CI Storage Array Controllers are supported

under OpenVMS V6.2-1H3 or later with CIPCA-

AA/BA or CIXCD-AC CI controllers; QB-5C4AA-

SA software kits are required for each external

cache (one for HSJ50, two for HSJ52, four for

HSJ54).

Controllers require KZPSA, KZPBA, KFPSA, or

CIPCA SCSI adapters or controllers, as

appropriate.

HSZ70 requires QB-5SBAB-SA/SB for Tru64 UNIX,

or QB-5SBAC-SA/SB for OpenVMS.

Fibre Channel controller (HSG80),

includes 2-MB cache expandable

to 128 MB; requires 128697-B21

HSG80 ACS V8.4F software kit or

128698-B21 V8.4P software kit

for each HSG80 ordered.

380672-B21

UltraSCSI controller (HSZ80),

includes 2-MB cache expandable

to 32 MB; requires 400569-001

for Tru64 UNIX or 400571-001 for

OpenVMS

400564-B21

UltraSCSI controller (HSZ80),

includes 2-MB cache expandable

to 128 MB; requires 400569-001

for Tru64 UNIX or 400571-001 for

OpenVMS.

400565-B21

StorageWorks UltraSCSI RAID Array

controller, includes 64-MB cache

expandable to 128 MB; requires

DS-HS35X-BC external cache

battery and HSZ70 kit .

DS-HSZ70-AH

32-MB cache 6-channel CI array

controller with cache battery

HSJ50-AF

128-MB cache 6-channel CI array

controller with cache battery

HSJ50-AJ

Dual 64-MB cache CI array controller

with cache batteries

HSJ52-AF

Dual 128-MB cache CI array

controller with cache batteries

HSJ52-AH

Dual 256-MB cache CI array

controller with cache batteries

HSJ52-AJ

Quad 512-MB cache CI array

controller with cache batteries

HSJ54-AJ
