Q
UICK
S
PECS
Standard Features
2 DA-10352-00A-001
Compaq AlphaServer GS60E
E X P A N D E D B A S E S E R V E R S
Processor
Two Alpha 21264 6/525 MHz processors (2 CPUs per module)
Cache Memory
4-MB ECC L2 onboard cache per CPU
Architecture
64-bit bus-based system architecture with seven system bus slots for CPU, memory, and I/O modules (1.87-
GB/sec sustained system bandwidth; 2.1-GB/sec peak bandwidth)
Upgradability
Supports additional processors, additional memory, additional I/O port modules, as well as storage and PCI I/O
module options; in-cabinet upgrade available to next generation Alpha 21264 microprocessors
Standard
2 CPUs on one CPU module
Maximum 6 CPUs on three CPU modules
System I/O Module and System I/O Expansion
System I/O module with four I/O channels (KFTHA-AA)
Standard
1
Maximum 3
RETMA PCI shelf mount box (DWLPB-DA)
Standard
1
Maximum 11 (with I/O Expansion Cabinets)
Memory
Standard 1 GB or 4 GB on one memory module
Maximum 12 GB
Network Controller
PCI 10/100 Mb Fast Ethernet adapter UTP
Expansion
Internal Drive Bays Seven to 28 available internal to system cabinet; up to 84 drive bays with I/O
expansion cabinet
Total PCI I/O Slots Up to 132 PCI I/O slots total with System and I/O Expansion Cabinets available and
no
internal storage (120 PCI I/O slots with internal storage and 10 DWLPB-DA PCI I/O
buses)
PCI 12-24 internal to System Cabinet
Storage
CD-ROM 5.25 ″ half height CD-ROM drive
Hard Drives 9.1-GB UltraSCSI disk drive (included)
18.2-GB, 36.4 GB UltraSCSI disk drives available
Diskette Drive Optional with Graphics Console Subsystem (3X-KFE72-LA)
Maximum Internal
Storage
1019.2 GB (36.4-GB disk drives)
Storage Controller/Shelf
UltraSCSI 1-port Single-ended adapter (KZPBA-CA)
UltraSCSI 16-bit StorageWorks shelf (BA36R-RC) and 1-m SCSI cable, VHDCI male-to-68 HD male (BN38C-
01)
Power Supplies
Redundant 48 VDC hot-swappable power supplies
M O D E L S
GS60E Tru64 UNIX Expanded
Base Servers
Two 6/525-MHz CPUs
9.1-GB UltraSCSI Hard Drive
DA-483GG-AA/AB
(4-GB memory)
DA-483GE-AA/AB
(1-GB memory)
GS60E OpenVMS Expanded
Base Servers
Two 6/525 MHz CPUs
9.1-GB UltraSCSI Hard Drive
DY-483GG-AA/AB
(4-GB memory)
DY-483GE-AA/AB
(1-GB memory)
- AA=120/208V US/Canada; 202V
Japan
-AB=380-415V Europe, 50/60 Hz
