PlateCrane EX User Manual Hudson Robotics, Inc.
33

Home Position: Proximity Switch for rotary and vertical arm home
(zero) ranging, with encoder homing pulse for final
home position.

Plate Present: Proximity switch

Plate Sensor: Proximity Switch.
4. Dimensions

Height: 28.5in. - 29.0in. (27.7in. w/out footpads)

Weight:

45 lbs.
5. Electrical

Power Input: 100-240V~, 50/60Hz, 110VA

Fuses: For 120V / 230V
Two 2A Time Delay, 5mm x 20mm
(.205 in. x .787 in.)

Grounding: Through the power cord, must be plugged into a
grounded outlet

Computer Interface: RS-232 serial cable
6. Environmental

Operating Temperature: 15

to 40

C (59

to 104

F)

Operating Humidity: 0 to 85%, no condensation

Storage Temperature: -20

to 65

C (-4

to 149

F)

Altitude: Up to 2000m

Ventilation Fans Require +2” of free space in front of them
 Indoor Use Only
