PlateCrane EX User Manual

Hudson Robotics, Inc.

8

Figure 10


2. Parts List


The PlateCrane EX carton(s) should include the following:

 PlateCrane EX
 2 Extruded Stacks (additional Stacks optional)
 Magazine Base (additional Bases optional)
 Power cord
 Communication cable
 User Manual (This document)
 CD containing SoftLinx and interfaces
 Teaching plate(s)
 Alignment Bases for instrument(s) (optional)
 Gripper jaws for PlateCrane Gripper (Includes Allen Wrench)
 Centering Plate for PlateCrane Gripper (Includes Allen Wrench)
 Allen screws to attach Bases to PlateCrane
 Allen Wrench for Magazine and Alignment Base(s)

Stack
installed
correctly
