207-093S Single RH UMC-RC Kit
* See washer note on page 34.
Callout Part Number
Quantity
in Kit
Part Description
803-169C 2 NUT HEX FLG. LOCK 1/2-13 PLT.
207-067D 2 UMC RC PIVOT TUBE
a
a. This part is a sub-assembly containing additional parts. See following tables.
207-142V 1 RIGID ROW CLEANER ASM RH
a
207-149S 1 UM ROW CLEAN DOWN STOP ASY
802-331C 2 RHSNB 1/2-13X1 3/4 GR5
804-017C 2 WASHER FLAT 1/2 USS PLT
804-029C 2 WASHER FLAT 1 SAE
817-615C 2 RC ARM PIVOT BUSHING
818-525C 1 DECAL SHARP OBJECT WARNING
207-095H 1 SINGLE ARM RC WLD RH
27334
32
37
39
32
32
32
207-093S SINGLE ARM RC ASM RH
*
*
*
38
*
38
*
38*
32
21
36
29
33
*
*
34
35
21
29
38
32
33
34
35
36
37
39
