Great Plains Manufacturing, Inc. Table of Contents Index Adjustment and Operation 17
2014-02-12 Table of Contents Index 204-085M-A
Adjusting UMC-RC Depth
Refer to Figure 22
1.
Raise the cleaner arm slightly. Loosen the nuts on
the adjuster stop
. Slide the stop forward.
2. Raise the row cleaner arm to slightly higher than
desired operating height and support it at this height.
3. Slide the adjuster stop up until it contacts the coulter
bracket. Tighten the nuts.
4. Relax the cleaner arm on the cross-tube and check
height relative to opener disks.
Figure 22:
UMC-RC Height Adjust
27341
1
1
