71 Simba SL
Operating Instructions
7. Parts and Assembly
AS4325
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00003 BOLT M12x40 GR. 8.8 2
2 P00006 BOLT M12x80 GR. 8.8 3
3 P00071 NIPPLE - GREASE 3
4 P00785 WASHER FLAT M30x10mm 3
5 P02007 NUT LOCK M12 5
6 P02011 NUT LOCK M30 3
7 P02483 LYNCH PIN CAT 1 1
8 P02601 WASHER FLAT M12 4
9 P05534 NUT LOCK M10 2
10 P09138 BOLT M10x60 GR. 8.8 2
11 P09162 TOOLBOX LID 1
12 P10017 TOOLBOX BODY 1
13 P15842 WING PIVOT PIN GREASER 3
14 P17623 PIN Ø30x140 TYPE P 1
15 P17625 PIN Ø30x180 TYPE P 1
16 P18254 WING FRAME RH - 6m DTD 2011 1
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
WING FRAME ASSEMBLY RH DTD 2011
