53 Simba SL
Operating Instructions
7. Parts and Assembly
AS3134 SIMBA SL HIGH CATCH
WING LOCK ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P15876 HIGH LATCH RH 1
2 P15877 HIGH LATCH LH 1
3 P14680 BUSH - PIVOT 2
4 P02604 WASHER FLAT M24 Ø50 2
5 P02010 NUT LOCK M24 2
6 P02008 NUT LOCK M16 2
7 P01358 NUT PLAIN M16 2
8 P02602 WASHER FLAT M16 4
9 P12886 Ø24xØ16x13mm SPACER BUSH 4
10 P02601 WASHER FLAT M12 4
11 P03087 BOLT M12x50 GR. 8.8 1
12 P02007 NUT LOCK M12 2
13 P03090 BOLT M12x70 GR. 8.8 1
14 H00170108 SPRING Ø4 L 149 2
15 P15264 SPRING RETAINING WASHER 2
16 P08817 WASHER SPRING M8 2
17 P09597 BOLT M8x25 GR. 8.8 2
18 P01901 BOLT M16x80 GR. 8.8 2
19 P00017 BOLT M24x100 GR. 8.8 2
