187

Simba SL

Operating Instructions

7. Parts and Assembly

AS3132

TURBO JET MOUNT KIT

SIMBA SL 4/5/6

ITEM

PART NO

DESCRIPTION

QTY

COMMENTS

1

AS2520

DISTRIBUTOR HEAD ASSEMBLY

14

2

AS3078

TURBOJET - GENERAL ASSEMBLY

1

3

P00003

BOLT M12x40 GR. 8.8

4

4

P00007

BOLT M16x40 GR. 8.8

5

5

P00015

BOLT M24x75 GR. 8.8

2

6

P00057

BOLT M16x60 GR. 8.8

3

7

P02007

NUT LOCK M12

4

8

P02008

NUT LOCK M16 'TYPE T'

5

9

P02010

NUT LOCK M24

2

10

P02012

NUT LOCK M36

2

11

P02038

WASHER SPRING M16

5

12

P02541

WASHER FLAT M36

4

13

P02601

WASHER FLAT M12

8

14

P02602

WASHER FLAT M16

13

15

P02604

WASHER FLAT M24 Ø50

4

16

P02789

BOLT M8x20 GR. 8.8

4

17

P03103

BOLT M16x30 GR. 8.8

2

18

P05399

BOLT M6x75 GR. 8.8

28

19

P05401

WASHER SPRING M6

55

20

P05534

NUT LOCK M10

28

21

P05535

WASHER FLAT M8

4

22

P07981

NUT LOCK M6

28

23

P08817

WASHER SPRING M8

4

24

P11644

DECAL - DO NOT RIDE

2

25

P11645

DECAL - HAND TRAP

3

26

P13961

BOLT U M10 GR8.8 71x88

14

27

P14710

NUT HALF M12

1

28

P15176

ACCESS PLATFORM

1

29

P15177

HAND RAIL - FL500

1

30

P15179

PLATFORM STEP

1

31

P15180

STEP LOCKING TAB

1

32

P15202

BUSH Ø50X16.25X8

2

33

P15708

RDS RADAR BRACKET

1

34

P15851

BOLT M36x120 GR. 8.8

2

35

P15858

OSR MOUNT BRACKET RH

1

36

P15859

OSR MOUNT BRACKET LH

1

37

P15860

OSR MOUNT TIE BAR

1

38

P15865

DECAL - STEP FOLDED UP

1

39

P15923

PLATFORM HANDLE CLAMP

1

40

P15924

BOLT PIN END

1

41

P15964

OSR SPREADER MOUNT

14

42

P15965

RADAR EXTENSION SL

1

43
44
45
46
47
48
49
50
