105 Simba SL
Operating Instructions
7. Parts and Assembly
AS4328 TINE FRAME ASSEMBLY LH 4M
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2962 ST TINE ASSEMBLY 5
2 AS3881 TINE BODY ASSEMBLY 5
3 P00014 BOLT M24x80 GR. 8.8 8
4 P01901 BOLT M16x80 GR. 8.8 5
5 P02008 NUT LOCK M16 'TYPE T' 5
6 P02010 NUT LOCK M24 8
7 P02602 WASHER FLAT M16 10
8 P02604 WASHER FLAT M24 Ø50 16
9 P05207 PIN Ø16x73 5
10 P05534 NUT LOCK M10 1
11 P10525 BOLT M10x60 GR. 8.8 1
12 P12911 CONVERTER 5
13 P16788 CIRCLE COTTER 52X2.6 5
14 P17626 PIN Ø30x200 TYPE P 1
15 P18239 TINE BEAM LH 4M 1
