AS4394 TINE FRAME ASSEMBLY LH 6m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2962 ST TINE ASSEMBLY 7
2 AS3881 TINE BODY ASSEMBLY 7
3 P00014 BOLT M24x80 GR. 8.8 8
4 P01901 BOLT M16x80 GR. 8.8 7
5 P02008 NUT LOCK M16 'TYPE T' 7
6 P02010 NUT LOCK M24 8
7 P02485 R CLIP Ø6x120 7
8 P02602 WASHER FLAT M16 14
9 P02604 WASHER FLAT M24 Ø50 16
10 P05207 PIN Ø16x73 7
11 P12911 CONVERTER 7
12 P15296 TOOLBAR LH 6M 1
