Page 163
163
Simba SL
Operating Instructions
7. Parts and Assembly
AS4307
HK - SL 4&5m QUICK LOCK
ITEM
PART NO
DESCRIPTION
QTY
COMMENTS
1
P00203
ADAPTOR MALE-MALE ½" BSP
10
2
P00205
QUICK RELEASE MALE - ½" BSP
5
3
P00206
ADAPTOR MALE-FEM ½" BSP
4
4
P00774
SHUT OFF TAP ½" BSP
6
5
P02263
DOWTY SEAL ½" BSP
21
6
P02735
BULKHEAD ½" BSP
4
7
P02741
DOWTY SEAL ¼" BSP
2
8
P02881
ADAPTOR MALE-MALE ¼" BSP
1
9
P04513
ADAPTOR MALE-MALE ½" BSP
1
10
P05162
ELBOW MALE-FEM 45° SWEPT ½" BSP
4
11
P07450
ADAPTOR T F/F/F ½" BSP
2
12
P08362
BANJO BLOCK 3/8" COMPLETE
2
13
P09112
CLAMP ½" BSP PAIR
13
14
P09113
CLAMP - TOP PLATE
11
15
P09141
CLAMP ¼" BSP
3
16
P09142
CLAMP PLATE ¼"
3
17
P09537
CAP FOR MALE - YELLOW
2
18
P09538
CAP FEMALE - YELLOW
2
19
P09539
CAP FOR MALE - RED
2
20
P09540
CAP FEMALE - RED
2
21
P09543
CAP FOR MALE - BLUE
1
22
P09726
BOLT M8x30 GR. 8.8
1
23
P10049
BOLT M8x25 STAUFF STACK
1
24
P10234
LOCK CLIP
1
25
P10278
BOLT M8x45 GR. 8.8
12
26
P12568
LOCK RING
2
27
P14095
ADAPTOR MALE 1/2" - FEMALE 3/8"
2
28
P15580
GENESIS WING BLOCK
1
29
P15581
CHECK PORT 1/4 BSP
2
30
P15645
GATES QL ADAPTER 60°
20
31
P15972
HA-1/2"X2265 QLH M/M
1
32
P15973
HA-1/2"X2165 QLH M/M
1
33
P15976
HA-1/2"X1110 QLH M/M
1
34
P15977
HA-1/2"X1110 QLH M/M
1
35
P15978
HA-1/2"X1110 QLH M/M
1
36
P15979
HA-1/2"X1110 QLH M/M
1
37
P15981
HA-1/2"X1110 QLH M/M
1
38
P15982
HA-1/2"X7340 QLH M/M
1
39
P15985
HA-1/2"X2120 QLH M/M
1
40
P15986
HA-1/2"X1900 QLH M/M
1
41
P15987
HA-1/2"X2930 QLH M/M
1
42
P15988
HA-1/2"X2930 QLH M/M
1
43
P15990
HA-1/2"X3620 QLH M/M
1
44
P15991
HA-1/2"X3620 QLH M/M
1
45
P15993
TWIN HOSE CLAMP
4
46
P16039
CYLINDER - Ø24x60 -16
1
47
P16391
DOC VALVE (REXROTH)
1
48
P16709
M/M 3/8" RESTRICTED
1
49
P16718
ADAPTOR F-F 1/4"-3/8"
1
50
P16741
1/4" HOSE 4205mm 3/8" F/F ENDS
1
51
P16742
BOLT M8x70 GR. 8.8
1
52
P16951
1/2" QRC FEM CUP UN PR
4
53
P18081
CYLINDER Ø120x310
1
54
P18204
ROD END - FRONT
2
55
P18261
CYL - BODY ONLY
2
