51 Simba SL
Operating Instructions
7. Parts and Assembly
AS4283 CHASSIS ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00071 NIPPLE - GREASE 2
2 P00896 NUT PLAIN M30 2
3 P02007 NUT LOCK M12 1
4 P02012 NUT LOCK M36 2
5 P02035 WASHER SPRING M10 2
6 P02600 WASHER FLAT M10 2
7 P02608 WASHER FLAT M30 4
8 P02652 BOLT M12x90 GR. 8.8 1
9 P02852 BOLT M36x180 GRS GR. 8.8 2
10 P04227 BOLT M30x120 GR. 10.9 2
11 P05122 SERIAL PLATE 1
12 P05401 WASHER SPRING M6 2
13 P06403 BOLT M10x20 GR. 8.8 2
14 P13672 BOLT M6x80 GR. 8.8 2
15 P17605 PIN Ø50x220 TYPE P 1
16 P18131 CHASSIS - REAR 1
17 P18147 LOOM PROTECTOR PLATE 1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
