Page 49

49
Simba SL
Operating Instructions
7. Parts and Assembly
AS3988
CLEVIS DRAWBAR ASSEMBLY
ITEM
PART NO
DESCRIPTION
QTY
COMMENTS
1
P00021
BOLT M24x140 GR.4.6
1
2
P00071
NIPPLE - GREASE
2
3
P00203
ADAPTOR MALE-MALE ½" BSP
6
4
P00205
QUICK RELEASE MALE - ½" BSP
2
5
P00407
BOLT M20x80 GR. 8.8
12
6
P01054
PIN Ø25x140
1
7
P01698
NUT CASTLE M60
1
8
P01796
M3/8"-F1/2"
2
9
P02007
NUT LOCK M12
4
10
P02010
NUT LOCK M24
2
11
P02035
WASHER SPRING M10
2
12
P02263
DOWTY SEAL ½" BSP
2
13
P02484
LYNCH PIN CAT 2
1
14
P02488
PIN SPLIT Ø5x75
2
15
P02489
PIN SPLIT Ø10x100
1
16
P02600
WASHER FLAT M10
2
17
P02601
WASHER FLAT M12
4
18
P02603
WASHER FLAT M20
12
19
P02604
WASHER FLAT M24 Ø50
2
20
P02608
WASHER FLAT M30
12
21
P02789
BOLT M8x20 GR. 8.8
2
22
P03090
BOLT M12x70 GR. 8.8
2
23
P03118
BOLT M24x300 GR. 8.8
1
24
P03482
BOLT M8x50 GR. 8.8
2
25
P03687
DOWTY SEAL 3/8" BSP
2
26
P03763
WASHER FLAT M30
2
27
P04010
WASHER FLAT M60x10
1
28
P04754
NUT LOCK M8
2
29
P05175
BOLT M30x90 GR10.9 FINE
6
30
P05400
WASHER FLAT M6
4
31
P05535
WASHER FLAT M8
4
32
P06641
ADAPTOR MALE - MALE 3/8"-3/8" BSP
1
33
P06651
BOLT M10x25 GR. 8.8
2
34
P07361
GREASE NIPPLE 45°
1
35
P07959
HA 1/2"x300
4
36
P07981
NUT LOCK M6
2
37
P08787
SCREW M12x35 CSK GR10.9
2
38
P08802
SHIM KIT 7 PIECE
1
39
P09092
HOSE STOWAGE PLATE
1
40
P09541
CAP FOR MALE - GREEN
2
41
P10882
BUSH Ø72xØ60x60 NYLON
2
42
P11645
DECAL - HAND TRAP
2
43
P11689
BOLT M8x110 GR. 8.8
1
44
P11694
DECAL - GREASE 10 HOURS
3
45
P11700
DECAL - MADE GREAT
1
46
P12950
BOLT M12x35 SOCKET CAP
4
47
P13013
MANUAL CASE Ø100
1
48
P13562
SCREW M6x25mm
2
49
P13920
BOLT M60x345
1
50
P14028
PIN Ø30x159
2
51
P14683
HOSE MAST
1
52
P14884
NUT LOCK M30 x 2mm
6
53
P15645
GATES QL ADAPTER 60°
2
54
P15726
DECAL-SIMBA GP 180X315
2
55
P15874
AIR VALVE TOP PLATE
1
56
P16108
DECAL - TURN ON WHEELS
1
57
P16312
MANUAL TUBE BRACKET
1
58
P16528
CLAMP ½" BSP PAIR
1
59
P17022
DRAWBAR - UPPER
1
60
P17025
HA-1/2"X2750 QLH M/F
1
61
P17026
SPACER TUBE
1
62
P17027
STAND CLEVIS D/B
1
63
P17028
PAD - WEAR
2
64
P17029
HA-1/2"X3125 QLH M/F
1
65
P17262
HA 3/8"x300
1
66
P17264
DECAL - GROUP OF 6 WARNING
1
67
P17295
HITCH - RING CAT 3 Ø41
1
68
P17527
DRAWBAR - LOWER
1
69
P17536
CYLINDER Ø120x310
1
70
P17541
SHIM COLLAR - TOP
1
71
P17542
SHIM COLLAR - BOTTOM
1
72
P18253
MANUAL - SL
1
73
74
75
