65 Simba SL
Operating Instructions
7. Parts and Assembly
AS2965 WING FRAME ASSEMBLY
LH 4M DTD
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00003 BOLT M12x40 GR. 8.8 2
2 P00006 BOLT M12x80 GR. 8.8 3
3 P00071 NIPPLE - GREASE 3
4 P00785 WASHER FLAT M30x10mm 3
5 P02007 NUT LOCK M12 5
6 P02011 NUT LOCK M30 3
7 P02483 LYNCH PIN CAT 1 1
8 P02601 WASHER FLAT M12 4
9 P09162 TOOLBOX LID 1
10 P10017 TOOLBOX BODY 1
11 P15487 WING FRAME LH 4M DTD 1
12 P15842 WING PIVOT PIN GREASER 3
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
