Center Frame Gang Assembly

Refer to Figure 6
Note: The gang assemblies

will be marked on the top

plates as to the location on disk as “left, front, cen-
ter”. This would refer to the left, front gang on the
center section. You may also refer to the machine
layout section for placement. The gang assembly
will be the same on both the narrow and wide cen-
ter except the wing hinge will be opposite on wide
center.

11. Remove the 1 x 3 Gr. 8 hex bolts

. Align holes in

plates of gang assemblies

to center frame plates

, secure with 1 x 3 Gr. 8 hex bolts

, 1 lock wash-

ers and 1 nuts.

12. Bolt may be tightened to specs, See “Torque Values

Chart” on page 24.

1

3

1

2

3

1

U

D

F

B

L

R

2

Figure 6

Center Frame Gangs

42132

3

1
