Great Plains 2025P Operator Manual - Manual (Page 45)

8/14/2006 118-928M
43 Adjustments
Refer to Figure 59
4. Pull seed meter wheel out about 1/4 inch, or
past the wheel drive pin, and spin backward to
clean out seeds from top pockets.
5. Remove seed meter wheel.
NOTE: With the seed meter wheel removed,
you may want to check the meter for internal
damage or trash.
Refer to Figure 60
6. Place new wheel on meter wheel shaft and
push meter slide retaining clip forward while
pushing in seed meter wheel.
Refer to Figure 61
7. Be sure slots in the center of seed meter
wheel are aligned with the wheel drive pin on
the meter shaft.
Figure 59
Remove seed meter wheel
22861
Spin wheel
backward before
removing
Retaining
clip
Figure 60
Place new seed meter wheel on wheel shaft
22862
Wheel
drive pin
Figure 61
Position seed meter wheel
22863
