Table 33 – Torque Values
Supply fan motor mounting 120 ¦ 12 in---lbs 13.5 ¦ 1.4 Nm
Supply fan motor adjustment plate 120 ¦ 12 in---lbs 13.5 ¦ 1.4 Nm
Motor pulley setscrew 72 ¦ 5 in---lbs 8.1 ¦ 0.6 Nm
Fan pulley setscrew 72 ¦ 5 in---lbs 8.1 ¦ 0.6 Nm
Blower wheel hub setscrew 72 ¦ 5 in---lbs 8.1 ¦ 0.6 Nm
Bearing locking collar setscrew 65 to70 in---lbs 7.3 to 7.9 Nm
Compressor mounting bolts 65 to75 in---lbs 7.3 to 7.9 Nm
Condenser fan motor mounting bolts 20 ¦ 2 in---lbs 2.3 ¦ 0.2 Nm
Condenser fan hub setscrew 84 ¦ 12 in---lbs 9.5 ¦ 1.4 Nm
