INSTALLATION AND OPERATION MANUAL
Models MF3700, MF3800
Page 800-345-6007 CumberlandStoveWorks.com
SPECIFICATIONS
Model Number MF3700, MF3800
BTU/hour input (1) 45,000 max
Heating Capacity (2) 2,400 Sq. Ft.
Electrical Rating (3) 110 Volts, 15 Amp,
60 Hz
Power Consumption Controller = 2.0 Watts
Stove = 200 Watts
Fuel Storage Capacity 62 lbs.
Flue Size (4) 3 in.
Width 22 in.
Height 40 in.
Depth 22 in.
Weight 287 lbs.
(1) Heat output will vary depending on the brand, type
and quality of fuel, and the moisture content. Consult your
dealer for best results.
(2) Based on post-1982 home construction, requiring 35
BTU/Hr. per Sq. Ft.
(3) Install per NFPA 70 and follow all state and local codes,
contact licensed electrical contractor for assistance.
(4) Install per NFPA 211 and follow all state and local codes,
contact licensed installers for assistance.
Listing label:
Tested to the following standards: UL1482, ASTM E1509,
ULC/ORD-C1482-M1990, and UCL S627-2000
GLASS SPECIFICATIONS
This stove is equipped with 5mm ceramic glass. Replace
glass only with Cumberland Stove Works ceramic glass
(PN 720002).
CAUTION
THIS INSTALLATION MUST CONFORM WITH LOCAL
CODES. IN THE ABSENCE OF LOCAL CODES YOU MUST
COMPLY WITH ASTM E150, (UM) 84-HUD, ULC/ORD-C-
148, AND
UCL S67-000.
CUMBERLAND STOVE WORkS, MANUFACTURER OF
THIS APPLIANCE, RESERVES THE RIGHT TO ALTER ITS
PRODUCTS, THEIR SPECIFICATIONS AND/OR PRICE
WITHOUT NOTICE.
13
9 "
8
1
14 "
1
4
1
4
7"
3
8
"
10 "
1638"
Figure 3: Intake and vent locations
