INSTALLATION AND OPERATION MANUAL
Models MF3700, MF3800
Page 7
800-345-6007
CumberlandStoveWorks.com
MAIN ASSEMBLY PARTS
kEY #
PART # DESCRIPTION
qYT.
1
710042
BASE
1
2
710106
FIREBOX W/AIRWASH
1
3
700076
POT CLEANINg ROD
1
4
700250
RIgHT UPRIgHT
1
5
700300
LEFT UPRIgHT
1
6
710008
FOOT
4
7
710110
FIREPOT
1
8
710053
ASH PAN ASSEMBLY
1
9
700147
STRAP
1
10
710057
INTAKE PIPE
1
11
730020
gASKET INTAKE
1
12
700335
UPPER STOVE BACK
1
13
700136
FLOOR STRAP
4
14
720044
AC INLET-OUTLET
1
15
700170
gRILL (gOLD, BLACK OR SILVER) 1
16
720045
POWER CORD
1
17
730006
730044
HOPPER/ASH PAN HANDLE (gOLD)
HANDLE (SILVER)
1
18
700365
DUCT COVER
1
19
700189
LEFT/RIgHT BAFFLE
2
20
720053
730042
CLEANINg ROD SPRINg (gOLD)
CLEANINg ROD SPRINg (SILVER)
1
21
730015
gASKET INBOARD AUgER
1
22
700337
LOWER STOVE BACK
1
23
700195
FILTER BRACKET
3
24
730031
HOPPER INSULATION
1
25
720034
90 DEgREE FITTINg
1
26
700202
UPPER BAFFLE
1
27
700163
SHELF BASE
1
28
700144
SHELF
1
29
730008
FILTER
1
30
700206
SCRAPER ROD
1
32
710095
gLASS DOOR ASSEMBLY
1
33
720073
VACUUM SWITCH
1
34
720052
CIRCULATINg BLOWER
1
35
720072
AIR PUMP
1
36
700257
CIRCULATINg AIR DUCT
1
37
710108
AUgER ASSEMBLY
1
38
700286
SPRINg CLIP
1
39
700269
SIDE PANEL
2
kEY #
PART # DESCRIPTION
40
710116
IgNITER PLUg (3700 ONLY)
1
41
710097
STOVE TOP
1
42
710098
FIREPLATE
1
43
730067
OUTBOARD AUgER gASKET
1
44
720015
PROOF OF FIRE SWITCH
1
46
700349
CONTROLLER BRACKET
1
47
730054
IM (INTERFACE MODULE)
1
48
730053
DISPLAY
1
49
700368
AIR PUMP PLATE
1
50
730032
HEAT TORCH
1
51
710010
HOPPER
1
52
710115
POTHOLDER
1
53
710103
EXHAUST MANIFOLD
1
57
730066
CIRC. BLOWER gASKET
1
59
710013
KIT HOPPER SWITCH
REPLACEMENT
1
62
725010
ADJUSTABLE gLIDE
4
63
720086
DISPLAY CABLE
1
64
720088
STRAIN RELIEF
1
65
700035
BRACKET DISPLAY
1
66
720085
SWITCH-HIgH LIMIT
1
ITEMS BELOW NOT SHOWN
--
8932 NUT 1/4-20 HKPSBW ZN
--
725017 NUT #10-24 HKPSBW ZN
--
1501A BOLT 5/16-18 X 3/4 HH gR5 ZN
--
503 BOLT 5/16-18 X 1-1/2 HH
--
63118 BOLT 1/4-20 X 1/2 HHCS gR5 ZN
--
725005 SCREW 1/4-20 X 1/2 TRUSS HD
TORX
--
725000 BOLT 10-24 X 3/8 TBHMS gR2
--
725012 BOLT 8-32 X 3/8 PPHMS gR2 ZN
--
725007 SCREW SLHH SHEET METAL
--
509 BOLT 1/4-20 X 1/2 SLHWH ZN
F-T T/C
--
725015 SCREW 1/4 X 2 LAg HH
--
725013 SCREW #6-20 X 3/4 PPH ZN
--
700034 STUD 10-24 X 3/4 STNLS FT
--
725016 SCREW #14 X 1/2 PTH BLK ZN
--
53611 NUT 5/16-18 H gR5 ZN
--
740001 WIRINg HARNESS
