To illustrate navigation through the main menu the following sequence of
down arrow key presses is shown. The up arrow can always be used to scroll
up through the list.
A pressed key is identified by a gray background, e.g.,.
From the measure screen,
press MENU to display the
list of options. Generally,
Calibration will be the first
option. To select a
calibration function, press
ENTER. Press the down
arrow to scroll through the
list. Press ESC to return to
the measure screen.
Pressing the down arrow from
Calibration will display
Configure. To select
Configure functions, press
ENTER To continue scrolling
the list, press the down arrow.
Press ESC to return to the
measure screen.
Pressing the down arrow from
Configure will display
DataStick Comms. To select
DataStick Comms functions,
press ENTER. To continue
scrolling the list, press the
down arrow. Press ESC to
return to the measure screen.
Note: The DataStick Comms
option is not available on
2020 ClearTrace System.
17
Main Menu
Calibrate
MENU ESC ENTER
Configure
DataStick Comms
Analog Output 1
Analog Output 2
Relay A
Relay B
Help
Reset AV38
Exit
Main Menu
Optional Features
t
t
t
t
t
t
t
t
t
t
t
t t
Main Menu
Calibrate
MENU ESC ENTER
Configure
DataStick Comms
Analog Output
Help
Reset AV38
Exit
Main Menu
Standard
t
t
t
t
t
t
t
t
t
t t
Main Menu
Calibrate
MENU ESC ENTER
t
t
t
t
t
Main Menu
Configure
MENU ESC ENTER
t
t
t
t
t
Main Menu
DataStick Comms
MENU ESC ENTER
t
t
t
t
t
ESC
Figure 4.1: The main menu (standard and optional feature lists)
