3
2.0 ELECTRICAL INSTRUCTIONS
2.1 General Instructions:
For a UL2108 Code compliant installation, the LEDstixx ® Strip must be installed with an
appropriate 24VDC, UL Listed, Class 2 power supply. For a list of UL Listed OPTOTRONIC ®
power supplies reference Section 2.2.
Pay attention to standard Electrostatic Discharge (ESD) precautions when installing the
system.
2.2 Power Supplies:
The maximum total length of LEDstixx Strip product that can be operated on some example
power supplies is shown below:
Item Power Supply Ordering Description Maximum total lineal feet per power supply
51514 OT75W/24V/UNV 25
51626 OT96W/24V/UNV/JBX 32ft
51598 OT50W/24V/120V/LP 17ft
51627 OT240W/3x24V/120-240V/JBX 25ft/channel
51622 OT17/120-277/24E 6ft
Note:
1. Ensure power supply has adequate power to operate the load.
2. Observe correct electrical polarity. Incorrect polarity may destroy the module.
3. To accurately determine maximum LED load, the de
–rating criteria listed in Application
Note “Determine the Maximum LED Load on the Constant Voltage Power Supplies” (#
LED026) must be factored in.
4.
To determine remote wiring distances, reference the Application Note “Remote Wiring
Distances for
LED Power Supplies” (# LED126).
