76-017-DB 11/13

OSRAM and Logo are registered trademarks of OSRAM GmbH.
ENCELIUM and Polaris 3D are registered trademarks of OSRAM SYLVANIA, Inc
GreenBus II are trademarks of OSRAM SYLVANIA, Inc.
SEE THE WORLD IN A NEW LIGHT is a registered trademark of OSRAM SYLVANIA, Inc.

©

2

0

1

3

O

S

R

A

M

S

Y

L

V

A

N

IA

0

1

-1

3







The Phase Cut Dimming Modules are to be installed in dry,
indoor locations ONLY.




There are no user-serviceable parts inside of the Phase Cut
Dimming Module. Please return the device to OSRAM
Sylvania Inc if service is required.












Note: This equipment has been tested and found to comply
with the limits for part 18 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct
the interference at his own expense.

Modifications not expressly approved by the manufacturer could
void the user's authority to operate the equipment under FCC
rules.




The contents of this Wiring and Installation Manual are subject
to change without notice.





The Phase Cut Dimming Module (PCDM) provides an
interface between the Phase Cut dimmable (forward
and reverse phase) ballasts/LED drivers and the
ENCELIUM GreenBus II™ communication network.
The PCDM is automatically addressed as soon as it is
connected to an Energy Control Unit (ECU).
Individually addressable, the PCDM enables each
group or zone of fixtures to be independently
controlled and configured to best meet the needs of
the facility.


The PCDM is designed to control popular load types
such as Incandescent/Halogen lamps, Fluorescent
ballasts, LED fixtures, and LED/CF lamps. The phase
cut dimmable fixtures connected to a PCDM can then be controlled by any of the Encelium low voltage
wall station controllers, the Touch Screen panel or from Polaris 3D™ software through the GreenBus
II™ communication network. PCDM has a built-in relay which provides ON/OFF switching control in
addition to smoothly dimming the fixtures.



The following model is available:

Indoor Locations:

EN-PCDM-GB2





When using electrical equipment, basic safety precautions should always be followed
including the following:

• READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• Do not let power supply cords touch hot surfaces.
• Do not mount near gas or electric heaters.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to

tampering by unauthorized personnel.

• The use of accessory equipment is not recommended by OSRAM Sylvania as it may cause an

unsafe condition.

• Do not use this equipment for other than the intended use.

SAVE THESE INSTRUCTIONS

Important Safeguards

Overview


ENCELIUM

Energy Management System

Phase Cut Dimming Module

Wiring and Installation Manual

www.sylvania.com/encelium

United States
OSRAM SYLVANIA
100 Endicott Street
Danvers, MA 01923
1-800-LIGHTBULB

Trade
Phone: 800-255-5042
Fax: 800-255-5043

National Accounts
Phone: 800-562-4671
Fax: 800-562-4674

OEM/Special Markets
Phone: 800-762-7191
Fax: 800-762-7192

Retail
Phone: 800-842-7010
Fax: 800-842-7011

SYLVANIA Lighting Services
Phone: 800-323-0572
Fax: 800-537-0784

Display/Optic
Phone: 888-677-2627
Fax: 855-543-1043

Canada
OSRAM SYLVANIA LTD.
2001 Drew Road
Mississauga, ON L5S 1S4
1-800-LIGHTBULB

Trade
Phone: 800-263-2852
Fax: 800-667-6772


OEM/Special Markets/Display/Optic

Phone: 800-265-2852
Fax: 800-667-6772


Retail

Phone: 800-720-2852
Fax: 800-667-6772


SYLVANIA Lighting Services

Phone: 800-663-4268
Fax: 866-239-1278

Mexico
OSRAM MEXICO
Tultitlan/Edo de Mexico
Phone: 011-52-55-58-99-18-50

ENCELIUM

®

Products

United States
Phone: 201-508-1570
Fax: 201-508-1589

Canada
Phone: 905-731-7678
Fax: 905-731-1401

www.sylvania.com

/Sylvania

/sylvania

Regulatory Approvals

Installation Notes

Troubleshooting
