SECTION 16

16.0

Tap Connections

Tap connections should not be used on a battery. This can

cause overcharging of the unused cells and undercharging of

those cells supplying the load, thus reducing battery life.

SECTION 17

17.0

Temporary Non-Use

An installed battery that is expected to stand idle longer

than the maximum storage interval (see Sec. 4.2), should be

treated as stated below. The maximum storage interval is 6

months if stored at 77°F.
Give the battery an equalizing charge as per Section 13.

Following the equalizing charge, open connections at the bat-

tery terminals to remove charger and load from the battery.

Repeat the above after every 6 months (77°F) or at the

required storage interval. See Section 4.2 for adjustments

to storage intervals when the storage temperature exceeds

77°F.

To return the battery to normal service, re-connect the battery

to the charger and the load, give an equalizing charge and

return the battery to float operation.

SECTION 18

18.0 Unit Cleaning

Periodically clean cell covers with a dry 2” paintbrush to

remove accumulated dust. If any cell parts appear to be damp

with electrolyte or show signs of corrosion, contact your local

GNB representative.

SECTION 19

19.0 Connections

Battery terminals and intercell connections should be cor-

rosion free and tight for trouble-free operation. Periodically

these connections should be inspected.

If corrosion is present, disconnect the connector from the ter-

minal.

Gently clean the affected area using a suede brush or Scotch

Brite scouring pad. Apply a thin coating of NO-OX-ID “A”

grease to the cleaned contact surfaces, reinstall connectors

and retorque connections to 11.3 Newton-meters (100 inch

pounds).

ALL TERMINAL AND INTERCELL CONNECTIONS SHOULD

BE RETORQUED AT LEAST ONCE EVERY YEAR TO 11.3

NEWTON-METERS (100 INCH POUNDS).

NOTE: Design and/or specifications subject to change

without notice. If questions arise, contact your local

sales representative for clarification.

SECTION 20

20.0 Capacity Testing

When a capacity discharge test is desired, it is recommended

that it be performed in accordance with IEEE-1188*, latest

revision.

An equalizing charge, as described in Section 13.2, must be

completed within 7 days prior to the capacity test. The bat-

teries must be returned to float charging immediately after the

equalize charge completes. Allow the batteries to float at least

72 hours prior to capacity discharge.

After the capacity discharge has completed, the batteries can

be recharged in the shortest amount of time by following the

equalize charge procedure described in Section 13.2.

*IEEE-1188: Recommended Practice for Maintenance,

Testing, and Replacement of Valve-Regulated Lead-Acid

(VRLA) Batteries for Stationary Applications.

CAUTION!

DO NOT WORK ON CONNECTIONS

WITH BATTERY CONNECTED TO

CHARGER OR LOAD.

!

CAUTION!

Do not clean plastic parts with solvents,

detergents, oils, mineral spirit or spray

type cleaners as these may cause crazing

or cracking of the plastic materials.

- 21 -
