GENERAL SPECIFICATIONS
Nominal kW 3 5 7.5 10 15
Fan Diameter
in. (mm) 12 (305) 12 (305) 12 (305) 12 (305) 16 (406)
Air Delivery
CFM (m 3 /hr) 700 (1190) 700 (1190) 700 (1190) 700 (1190) 1450 (2460)
Approx. Air Velocity
ft/m (m/s) 785 (4.0) 785 (4.0) 785 (4.0) 785 (4.0) 950 (4.8)
Horizontal Throw ft. (m) 22 (6.7) 22 (6.7) 22 (6.7) 22 (6.7) 35 (10.7)
Max. Mounting Height* (ft.) 8.5 8.5 8.5 8.5 11.5
horizontal (to underside) (m) 2.6 2.6 2.6 2.6 3.5
Max. Mounting Height*
(ft.) 12.8 12.8 12.8 12.8 18.0
45° decline (to underside) (m) 3.9 3.9 3.9 3.9 5.5
Min. Mounting Height
(ft.) 6.0 6.0 6.0 6.0 6.0
(m) 1.8 1.8 1.8 1.8 1.8
Net Weight lbs. (kg) 75.0 (34.1) 75.0 (34.1) 75.0 (34.1) 75.0 (34.1) 90.0 (40.9)
Shipping Weight lbs. (kg) 125.0 (56.8) 125.0 (56.8) 125.0 (56.8) 125.0 (56.8) 140.0 (63.6)
Temperature Limitations Storage: -49°F to 140°F (-45°C to 60°C)
Operating: -49°F to 104°F (-45°C to 40°C)
Nominal kW 20 25 30 35 39
Fan Diameter
in. (mm) 16 (406) 20 (508) 20 (508) 20 (508) 20 (508)
Air Delivery
CFM (m 3 /hr) 1450 (2460) 2100 (3570) 2100 (3570) 2100 (3570) 2100 (3570)
Approx. Air Velocity
ft/m (m/s) 950 (4.8) 900 (4.6) 900 (4.6) 900 (4.6) 900 (4.6)
Horizontal Throw
ft. (m) 35 (10.7) 44 (13.4) 44 (13.4) 44 (13.4) 44 (13.4)
Max. Mounting Height* (ft.) 11.5 12.3 12.3 12.3 12.3
horizontal (to underside) (m) 3.5 3.7 3.7 3.7 3.7
Max. Mounting Height*
(ft.) 18.0 18.8 18.8 18.8 18.8
45° decline (to underside) (m) 5.5 5.7 5.7 5.7 5.7
Min. Mounting Height
(ft.) 6.0 6.0 6.0 6.0 6.0
(m) 1.8 1.8 1.8 1.8 1.8
Net Weight lbs. (kg) 90.0 (40.9) 130 (59.1) 130 (59.1) 130 (59.1)) 130 (59.1)
Shipping Weight lbs. (kg) 140.0 (63.6) 180 (81.8) 180 (81.8) 180 (81.8) 180 (81.8)
Temperature Limitations Storage: -49°F to 140°F (-45°C to 60°C)
Operating: -49°F to 104°F (-45°C to 40°C)
* Maximum mounting height to ensure warm air reaches the floor.
