Acetileno:16,694,094.2 Butano:38,316,921 Gas na
tural:11,356,526.7
Propano:27,914,342.6
• • • •
Ma
pp:
27,323,803.2
Metano:11,356,526.7 Propileno:26,926,324.8
• • •
TIPOS 1-101,
3-101 (Oxiacetileno)
Oxígeno de corte
Acetileno
Espesor del
metal
Tama
-
ño
de la punta
Presión***
kg/cm
2
/ PSIG
Flujo*** m
3
bajo
condiciones
estándar / SCFH
Precalentamiento
Oxígeno*
kg/cm2 / PSIG
Presión
kg/cm2 / PSIG
Flujo m3 bajo
condiciones
estándar /
SCFH
velocidad IPM = m/seg / IPM
En
-
talla
-
dura An
-
cho
0.317 cm / 1/8”
0
1.4061-1.7576 / 20-25
0.5663-0.7079 / 20 -25
0.2109-0.3515 / 3-5
0.2109-0.3515 / 3-5
0.1699-0.3114 / 6-11
0.0084-0.0127 / 20-30
0.04
0.635 cm / 1/4”
0
1.4061-1.7576 / 20-25
0.8495-0.9910 / 30-35
0.2109-0.3515 / 3-5
0.2109-0.3515 / 3-5
0.1699-0.3114 / 6-11
0.0084-0.0118 / 20-28
0.05
0.952 cm / 3/8”
0
1.7576-2.1092 / 25-30
1.5574-1.6990 / 55-60
0.2109-0.3515 / 3-5
0.2109-0.3515 / 3-5
0.1699-0.3114 / 6-11
0.0076-0.0110 / 18-26
0.06
1.27 cm / 1/2”
0
2.1092-2.4607 / 30-35
1.6990-1.8405 / 60-65
0.2109-0.4218 / 3-6
0.2109-0.3515 / 3-5
0.2548-0.4530 / 9-16
0.0067-0.0093 / 16-22
0.06
1.905 cm / 3/4”
1
2.1092-2.4607 / 30-35
2.2653-2.4069 / 80-85
0.2812-0.4921 / 4-7
0.2109-0.3515 / 3-5
0.2265-0.3681 / 8-13
0.0063-0.0084 / 15-20
0.07
2.54 cm / 1”
2
2.4607-2.8122 / 35-40
3.9643-4.5306 / 140-160
0.2812-0.5624 / 4 -8
0.2109-0.4218 / 3-6
0.2831-0.5097 / 10-18
0.0055-0.0076 / 13-18
0.09
5.08 cm / 2”
3
2.8122-3.1638 / 40-45
5.9465-6.7960 / 210-240
0.3515-0.7030 / 5-10
0.2812-0.5624 / 4-8
0.3964-0.6796 / 14-24
0.0042-0.0050 / 10-12
0.11
7.62 cm / 3”
4
2.8122-3.5153 / 40-50
7.9287-9.0613 / 380-320
0.3515-0.7030 / 5-10
0.3515-0.7733 / 5-11
0.5097-0.7928 / 18-28
0.0042-0.0050 / 10-12
0.12
