7-20
note
Approximate gross BTU contents per cubic foot:
Acetylene - 1470
Butane - 3374
Natural Gas - 1000
Propane - 2458
•
•
•
•
Mapp - 2406
Methane - 1000
Propylene - 2371
•
•
•
warning
At no time should the withdrawal rate of an individual acetylene cylinder exceed
1/7 of the cylinder contents per hour. If additional flow capacity is required, use an
acetylene manifold system of sufficient size to supply the necessary volume.
CaUtion
Always make sure your equipment is rated for the size tip you have selected. A tip
with too much capacity for the equipment can starve or choke the tip. This causes
overheating of the head and a backfire may result. Use only genuine VICTOR ® ,
Cutskill ® , or Firepower ® cutting tips, welding nozzles and multi-flame nozzles to
ensure leak-free connections and balanced equipment.
tYpes 303M, GpM, GpN, Gpp
cutting oxygen pre-heat Fuel Gas
Metal
thickness
tip
size
pressure
*** psIG
Flow
scFh
pre-
heat
oxygen
psIG
pressure
psIG
Flow
scFh
speed
IpM
kerf
width
1/8" 000 20 - 25 12 - 14
See
Note,
page
23
3 - 5 5 - 6 20 - 30 .04
1/4" 00 20 - 25 22 - 26 3 - 5 5 - 7 20 - 28 .05
3/8" 0 25 - 30 45 - 55 3 - 5 8 - 10 18 - 26 .06
1/2" 0 30 - 35 50 - 55 3 - 5 8 - 10 16 - 22 .06
3/4" 1 30 - 35 70 - 80 4 - 6 10 - 12 15 - 20 .08
1" 2 35 - 40 115 - 125 4 - 8 12 - 15 13 - 20 .09
1 1/2" 2 40 - 45 125 - 135 4 - 8 12 - 15 13 - 18 .09
2" 3 40 - 45 150 - 175 5 - 9 14 - 18 11 - 13 .10
2 1/2" 3 45 - 50 175 - 200 5 - 9 14 - 18 10 - 12 .10
3" 4 40 - 50 210 - 250 6 - 10 16 - 20 8 - 10 .12
4" 5 45 - 55 300 - 360 8 - 12 20 - 30 6 - 9 .14
5" 5 50 - 55 330 - 360 8 - 12 20 - 30 4 - 7 .14
6" 6 45 - 55 400 - 500 10 - 15 25 - 35 3 - 5 .17
8" 6 55 - 65 450 - 500 10 - 15 25 - 35 3 - 4 .18
12" 8** 60 - 70 750 - 850 10 - 14 25 - 120 3 - 4 .41
