MFN heAtING NozzLes
propane cubic
Feet per hour
oxygen cubic
Feet per hour
tip
size
propane
pressure
Range
(psIG)
oxygen
pressure
Range
(psIG)
Min
Max
Min
Max
BtU per
hour
8
10-15
10-20
10
35
40
140
See
Note,
page
23
10
12-20
10-30
20
80
80
320
12*
15 - 25
30 - 125
30
160
120
640
15*
15 - 25
30 - 125
50
200
200
800
20*
20 - 30
40 - 135
75
250
300
1000
*Use model HD310C torch and 3/8" hose.
tYpes 1-101, 3-101 (oXY-AcetYLeNe)
cutting oxygen
Acetylene
Metal
thickness
tip
size
pres-
sure***
(psIG)
Flow***
(scFh)
pre-heat
oxygen*
(psIG)
pres-
sure
(psIG)
Flow
(scFh)
speed
(IpM)
kerf
width
1/8"
000 20 - 25
20 - 25
3 - 5
3 - 5
6 - 11 20 - 30 .04
1/4"
00
20 - 25
30 - 35
3 - 5
3 - 5
6 - 11 20 - 28 .05
3/8"
0
25 - 30
55 - 60
3 - 5
3 - 5
6 - 11 18 - 26 .06
1/2"
0
30 - 35
60 - 65
3 - 6
3 - 5
9 - 16 16 - 22 .06
3/4"
1
30 - 35
80 - 85
4 - 7
3 - 5
8 - 13 15 - 20 .07
1"
2
35 - 40 140 - 160
4 - 8
3 - 6 10 - 18 13 - 18 .09
2"
3
40 - 45 210 - 240
5 - 10
4 - 8 14 -24 10 - 12 .11
3"
4
40 - 50 280 - 320
5 - 10
5 - 11 18 - 28 10 - 12 .12
4"
5
45 - 55 390 - 450
6 - 12
6 - 13 22 - 30 6 - 9
.15
6"
6** 45 - 55 500 - 600
6 - 15
8 - 14 25 - 35 4 - 7
.15
10"
7** 45 - 55 700 - 850
6 - 20
10 - 15 25 - 35 3 - 5
.34
12"
8** 45 - 55 900 - 1050
7 - 25
10 - 15 25 - 35 3 - 4
.41
*
Applicable for three-hose machine cutting torches only. With a two-hose cuting torch,
preheat pressure is set by the cuttting oxygen.
** For best results use HC1200C series torches and 3/8" hose using a size 6 tip or
larger.
*** All pressures are measured at the regulator using 25' x 1/4" hose through tip size 5,
and 25' x 3/8" hose for tip size 6 and larger.
