4.05 Power Source Compatibility
The Ultrafeed VA 2000 wire feeder will work with any Ther-
mal Arc CV or CC/CV power source. If the Thermal Arc
power source only offers a 5 pin amphenol connector
and AC voltage outlets, an 870000-001 adapter cable will
be required to connect between the 19 pin control cable
of the wire feeder and the 5 pin amphenol connector and
AC voltage outlets of the power source.
If the Thermal Arc power source only offers a 14 pin
amphenol connector, an 870093B-001 adapter cable will
be required to connect between the 19 pin control cable
of the wire feeder and the 14 pin amphenol connector of
the power source.
The Ultrafeed VA 2000 will also work with most competi-
tive power sources that provide 115 VAC and require a
relay closure to become energized.
4.06 Power Source Compatability Details
Machine Details
PowerMaster 500 Fully Compatible
PowerMaster 500P Fully Compatible
ExcelArc 6045 Fully Compatible
ExcelArc 8065 Fully Compatible
Fabstar 4030 Fully Compatible
Arc Master 300 MST Fully Compatible
Arc Master 400 MST Fully Compatible
Arc Master 400 MSTP Fully Compatible
Power Source Compatibility Details
Figure 4-5: Power Source Compatability
