Diagrams – Tweco SP 2001 Spool Gun User Manual
Page 27
DIAGRAMS
•
Note the model and specification number shown on the equipment nameplate.
•
Locate these numbers in the model and specification number columns below.
•
Use only those diagrams and instructions that are applicable.
MODEL
SPECIFICATION
NUMBER
CONNECTION &
SCHEMATIC
DIAGRAM
SYSTEM
OUTLINE
SP-2001
407838B-1
FIGURE 7-1
870106
SP-2001
407838B-2
FIGURE 7-1
870106
430429-287
DIAGRAMS
April 6, 1998 Revised
7-1
