40
407885
. . Motor - 1/2 Shaft
1
All
41
No Number
. . Screw - 4-40 x 1/2 Rd. Hd.
2
All
42
No Number
. . Screw - 4-40 x 3/8 FL. Hd.
1
All
43
407890
. . Roll - Feed
1
All
44
No Number
. . Screw - Set, 8-32 x 1/8
1
All
45
171405
. . Handle - Gun
1
All
46
409315
. . Cup - Retaining Switch
1
All
47
No Number
. . Screw - 8-32 x 3/4 Rd. Hd.
2
All
48
409301
. . Switch - Wired
1
All
49
409308
. . Trigger
1
All
50
409319
. . Spring - Trigger
1
All
51
409317
. . Barrel - Space/Seal, 3 Inch
2
All
52
409316
. . Barrel - Outer Sleeve, 3 Inch
1
All
53
409318
. . Insulator - Barrel Sheath, 3 Inch
1
All
54
409313
. . Barrel - 3 Inch
1
All
55
409305
. . Liner - Barrel, 3 Inch
1
All
56
409310
. . Cover - Top
1
All
57
409304
. . Hand Nut - Top Cover
1
All
58
409314
. . Ring - Snap
2
All
59
407887
. . Spacer - Pressure Roll
1
All
60
407889
. . Roll - Pressure
1
All
61
407899
. . Bushing - Pressure Roll
1
All
62
170493
. . Block - Body
1
All
171310-1
. Hose & Cable - Assembly, W/Fittings 50’
1
A
171310-2
. Hose & Cable - Assembly, W/Fittings 25’
1
B
63
407930
. . Fitting - Power Cable
1
All
64
407928
. . Ferrule - Hose
2
All
65
407925-1
. . Cable - Weld 50’
1
All
66
407932-1
. . Hose - 3/8" x 50’
1
All
67
407926
. . Fitting - Cable
1
All
68
407927
. . Nut - Gas
1
All
171406-2
. . Trigger Cord - Assembly, W/Fittings 50’
1
A
171406-1
. . Trigger Cord - Assembly, W/Fittings 25’
1
B
69
171409
. . . Plug - 6 Socket
1
All
70
171413-2
. . . Cord - Trigger 50’
1
A
171413-1
. . . Cord - Trigger 25’
1
B
71
171411
. . . Plug - Amphenol, 6 Pin
1
All
72
407865
. . Ring — “O”
1
All
73
171414
. . Potentiometer - 5K Ohm
1
All
74
171412
. . Dial - Feed
1
All
75
171410
. . Knob - Control
1
All
Item
Part
Description
Qty Application
No
Number
per
Code
Assy
Parts List For Figure 6-1
430429-287
PARTS LIST
April 6, 1998 Revised
6-5
